The single phase 4P digital din rail meter is a new type of single-phase all-electronic watt-hourmeter developed by our company using microelectronic technology to measure electric energy, imported special large-scale integrated circuit, digital processing technology and SMT technology. The meter fully meets the relevant technical requirements of Grade 1 or Grade 2 single-phase watt-hour meter in GB/T17215.321-2008 national standard and lEC62053 international standard, and can directly and accurately measure the positive active electric energy in electric energy metering, and the total electric consumption is displayed by a 6-bit meter, it has the characteristics of high reliability, small size, light weight, beautiful appearance, advanced technology and 35mm DIN standard guide rail installation; And has good anti-electromagnetic interference, low power consumption, high precision, high overload, high stability,anti-stealing electricity.
Technical Specifications
|
Parameter Category |
Specific Specifications |
|
Display Method |
LCD Display |
|
Rated Voltage |
220V |
|
Rated Current |
5(20)A 10(40)A 15(60)A 20(80)A |
|
Accuracy Class |
Class 1.0 |
|
Installation Method |
35mm rail installation |
|
Dimensions |
105×85×73mm (±1mm) |
Core Advantages
1.Higher Power Bearing Capacity
It can stably power high-power devices such as air conditioners, electric water heaters, and commercial equipment without overheating or burnout.
2.Tunnel-type Terminal Blocks
Built-in thickened terminal posts made of copper, featuring excellent electrical conductivity and high-temperature resistance, as well as corrosion resistance and ductility.
Differences between 2P and 4P meters
1.Power Bearing Capacity
Generally speaking, the rated current of a single phase 2P meter ranges from 5A to 60A, while the rated current of a single phase 4P digital din rail meter can reach 80A or even 100A. Therefore, the 4P meter can bear a relatively larger power.
2.Applicable Scenarios
The 4P meter is suitable for high-power, high-safety scenarios (e.g., commercial stores, rental houses); the 2P meter is more suitable for medium/low-power, simple scenarios (e.g., home basic circuits, small lighting loops).
3.Anti-tampering Performance
The 4P meter has a sealed full-pole structure, which reduces the risk of metering tampering (e.g., neutral wire bypass); the 2P meter has no neutral wire access, making it easier to tamper with via external neutral wire connections.
